2027 KX85

£4,649.00

Make an Enquiry Test Ride Enquiry Part Exchange Enquiry

Model Description


Powered by a proven 84cc engine combined with a chassis designed to maximize engine performance, the KX85 motorcycle is engineered to give young racers a competitive edge. With factory-inspired components and a choice of wheel sizes to accommodate a wider range of riders, these serious race machines help carve the path to the podium.

Model Specification


  • Engine

    Engine type

    Liquid-cooled, 2-stroke Single with KIPS

    Displacement

    84 cc

    Bore x stroke

    48.5 x 45.8 mm

    Compression ratio

    10.9:1 (low speed); 9.0:1 (high speed)

    Valve/Induction system

    Piston Reed valve

    Fuel system

    Carburettor: Keihin PWK 28

    Ignition

    Digital CDI

    Starting

    Primary kick

    Lubrication

    Petrol Mix

    Battery Type

    Nominal Voltage

    Total Nominal Capacity

    Charging Time

    Maximum Charge Cycles

    Max Permissible Load

    Rated Output

  • Transmission

    Transmission

    6-speed

    Final Drive

    Chain

    Primary reduction ratio

    3.400 (68/20)

    Gear ratios: 1st

    2.538 (33/13)

    Gear ratios: 2nd

    1.875 (30/16)

    Gear ratios: 3rd

    1.500 (27/18)

    Gear ratios: 4th

    1.250 (25/20)

    Gear ratios: 5th

    1.090 (24/22)

    Final reduction ratio

    3.643 (51/14)

    Clutch

    Wet multi-disc, manual

    Gear Ratios: 6th

    0.956 (22/23)

  • Frame

    Frame type

    Perimeter, high-tensile steel

    Rake/Trail

    29.2º / 103 mm

    Wheel travel - front

    275 mm

    Wheel travel - rear

    275 mm

    Tyre - front

    70/100-17 40M

    Tyre - rear

    90/100-14 49M

    Steering angle - left / right

    39° / 39°

  • Suspension

    Suspension - front

    43 mm inverted fork with adjustable compression and rebound damping

    Suspension - rear

    Uni Trak, single shock with adjustable compression and rebound damping and adjustable spring preload

  • Brakes

    Brakes - front

    Single 240 mm petal disc. Caliper: Dual-piston

    Brakes - rear

    Single 220 mm petal disc. Caliper: Single-piston

  • Dimensions

    Dimensions (L x W x H)

    1,835 x 800 x 1,115 mm

    Wheelbase

    1,265 mm

    Ground Clearance

    295 mm

    Seat height

    830 mm

    Fuel capacity

    5 Litres

    Curb Mass

    76.4 kg* | *Curb mass includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).

  • Performance

    Max Speed

    Running Time
